4+1 CCTV CABLEPolycab

bt_bb_section_bottom_section_coverage_image
Product Product Product

KEY FEATURES

  • Power and Data hybrid type construction
  • Communication and electrical conductors combined
  • Single Video Core and Four power cores
  • Flame retardant cable with CCA braiding on video core

  • Electrical Parameters
  • Construction
  • Conductor Resistance (DC) of Solid: 65 Ω/km @20⁰C. (Max)
  • Conductor Resistance (DC) of Stranded: 175 Ω/km @20⁰ C. (Max)
  • Tensile Strength in PVC Jacket – 12.5 N/mm (Min)
  • Elongation in PVC Jacket – 150% (Min)
Power Core Conductor
Conductor Type Stranded Annealed Bare Copper Conductor
No. of Wire/Size of Wire (Nos./mm) 14/0.10 ± 0.010 mm
Insulation PVC
No. of Core 4
Colour Code Red, Yellow, Grey & Blue
Core O.D. 1.35 ± 0.10 mm
Video Core
Conductor Type Solid Annealed Bare Copper Conductor
No. of Wire/Size of Wire (Nos./mm) 01/0.60 ± 0.015 mm
Insulation HDPE
No. of Core 1
Colour Code Natural
Shield (Video Core Shielding)
Shielding Al-Mylar
Braiding CCA braiding (48 wire/0.12 ± 0.01 mm)
Video Core Jacketing HDPE
Colour of Jacket Black
Video Core OD 2.50 ± 0.20 mm
Outer Sheath
Material PVC
Colour of Jacketing (As per Customer Required) White
Thickness of Outer Jacket 0.65 mm (Nom.)
Outer Dia. 5.70 ± 0.30 mm
Sequential Marking At Every Meter
