KEY FEATURES
- Performance verified to 250 MHz
- 4 Pair 23 AWG
- Shielding, GI wire armouring
- High speed transmission of Voice, Video and Data on LAN
- Complies to ANSI/TIA-568-C.2, ISO/IEC 11801 Class E
- Mechanical Properties
- Electrical Properties
- Colour Code
- Conductor: 23 AWG Solid Bare Copper
- Central Separator: PE Cross Separator
- Insulation: High Density Polyethylene
- Solid Pairs: 4 Pairs Twisted together
- Rip cord: Nylon Rip cord
- ATC Braiding
- Inner Jacket: FR-PVC, Grey
- Armouring: GI wire
- Outer Jacket: FRLS PVC, Grey
- Cable Diameter: 11.0 ± 1.5 mm
- Bending Radius: 12 X OD at 20°C
- Pulling Force: 25 lbs
- Operating Temperature: (-10°C to +60°C)
- Installation Temperature: (0°C to +50°C)
- Conductor Resistance: 9.2 Ω/100 Mtr max
- Mutual Capacitance: 5.6 nF for 100 Mtr
- Resistance Unbalance (%): max 5
- Capacitance Unbalance: 330 pF for 100 Mtr
- Delay Skew: 48 ns/100 Mtr
- Propagation Delay: < 538 ns/100 Mtr
- NVP: 69%
- Current Rating: max 1.5 A
- Operating Voltage: 72 V
- Pair Number: Colour
- 1 – 2 : White-Orange Strip and Orange
- 3 – 6 : White-Green Strip and Green
- 4 – 5 : White-Blue Strip and Blue
- 7 – 8 : White-Brown Strip and Brown
