UNI-TUBE SINGLE SHEATH
UNARMOURED CABLE SM &
MM (2F-24F) WITH 2 FRP RODSPolycab

bt_bb_section_bottom_section_coverage_image
Product Product Product

APPLICATIONS & FEATURES

  • Suitable for Duct Installation
  • Used for CATV and other networks
  • Light in weight
  • Small cable diameter
  • Ease of Installation
  • Available up to 24 Fibers

  • Construction Details
  • Other Info.
  • Technical Info.
  • Non metallic, anti-buckling FRP Rod as Strength Member embedded in sheath
  • Single Loose tube filled with thixotropic jelly and centrally palced in the cable
  • Outer sheath with UV Stabilised HDPE Compound
  • Fiber Count 2F-24F (SM Fiber G.652D, G.655, G.657 and Multi Mode OM1, OM2, OM3 & OM4)
Options Available On Request
  • Metallic strength members/Composite fibers/ Customised designs/Aramid or Glass Yarns/Rip Cord (s)/FR-PVC/LSZH
Drum Length
  • 2000 meters ± 10% or as per customer’s requirement
Environmental Conditions (IEC 60794-1-2f1)
  • Operating Temperature : -30˚C to + 70˚C
  • Storage Temperature : -30˚C to + 70˚C
  • Installation Temperature : -20˚C to + 70˚C
International Standards
  • IEC 60794; IEC 60793; ITU-T Rec. G.650; ITU-T Rec. G.652; ITU-T Rec. G.655; ITU-T Rec. G.656; ITU-T Rec G.657 En187000; Telecordia GR-20 issue 3rd May, 2008
Technical Data
FIBER COUNT OUTER DIAMETER (NOMINAL) WEIGHT (KG/KM) TENSILE STRENGTH (N) BENDING RADIUS
TEMPORARY PERMANENT TEMPORARY PERMANENT
2F – 12F 5.2 mm 21 400 200 15D 20D
24F 6.5 mm 35 600 300 15D 20D
Fiber Transmission Performance
PARAMETERS MULTI MODE SINGLE MODE
Fiber Core Diameter (µm) 62.5 50 50 50 9
Fiber Category OM1 OM2 OM3 OM4 G.652D
Wavelengths (nm) 850/1300 850/1300 850/1300 850/1300 1310/1550/1625
Maximum Attenuation (dB /km) 3.5/1.5 3.0/1.0 3.0/1.0 3.0/1.0 0.36/0.23/0.26
Bandwidth (MHz*km) 850/1300 200/500 500/500 1500/500 3500/500 N/A
